Vehicle Technical Specifications
| Item | Technical Parameters | Item | Technical Parameters |
|---|---|---|---|
| Product Name | Truck-mounted crane transport vehicle | Product Model | CLW5180JSQBSZ |
| Gross Mass (kg) | 18000 | Overall Dimensions (mm) | 9000,8720,8260,7410×2550,2500×3880,3780,3680,3580 |
| Rated payload (kg) | 5810,5745,6770,6705 | Cargo box dimensions (mm) | 5800,5600,5400,5200,5100,5000,4500,4400,4300,4200 ,6200,6100,6050,6000,5900×2450,2400,2350,2300×550,600 |
| Curb Weight (kg) | 12060 / 11100 | Front/Rear Overhang (mm) | 1290/2610,1290/2630,1290/2470,1290/2170 |
| Permitted number of passengers in the cab (persons) | 2,3 | Maximum Speed (km/h) | 90 |
| Approach/Departure Angle (°) | 19 / 11 | Axle Load (kg) | 6500/11500 |
Chassis Technical Specifications
| Item | Technical Parameters | Item | Technical Parameters |
|---|---|---|---|
| Chassis Model | BJ1184VKPFN-02 | Chassis Name | Cargo truck chassis |
| Number of Axles | 2 | Number of Tires | 6 |
| Wheelbase (mm) | 4500,4800,5250,5100,3950 | ||
| Tire Specifications | 10.00R20 18PR,11R22.5 18PR,295/60R22.5 18PR,315/70R22.5 18PR,295/80R22.5 18PR | ||
| Number of leaf springs | 10/12+9,10/10+9,4/10+3,10/-,8/10+6 | Front track (mm) | 1900,1960,1920,1940 |
| Fuel Type | Diesel Fuel | Rear track (mm) | 1810 / 1860 |
| Emission Standard | GB17691-2018 National Standard Ⅵ | ||
Performance Characteristics
1.The ABS model is CM4XL-4S/4M.
2.The crane model, crane weight (kg), and maximum lifting load (kg) are S200, 3,950, and 8,000, respectively.
3.The optional articulated crane model/crane weight (kg)/maximum lifting capacity (kg) is: SQZ160/3950/8000.
4.The correspondence between the engine and fuel consumption (L/100km) is as follows: WP4.6NQ220E61/25.89, YCS06245-60/24.58, YCS06270-60/24.58.
5.Optional rear-mounted tool box and tool box style; optional direct-power ETC on-board unit; equipped with a vehicle data recorder featuring satellite positioning capabilities.
6.Optional cab, cargo box style, crane type, crane seating configuration (mid-mounted, high-mounted, or no seat), as well as rear outrigger shape, radiator shape, and installation position, are available depending on the chassis.
7.The side guards are made of Q235 steel and attached via welding; the rear guard is made of Q235A steel and attached via welding. The cross-sectional dimensions of the rear guard are 60 mm × 120 mm, and the ground clearance of the rear guard is 485 mm.
8.The corresponding values for overall vehicle length (mm), wheelbase (mm), and rear overhang (mm) are: 9000/5100/2610, 8720/4800/2630, 8260/4500/2470, and 7410/3950/2170.
9.The optional crane models, crane weights (kg), and maximum lifting capacities (kg) are as follows: HST8/3950/8000,S200/3950/8000,SQS200/3950/8000,URV804/3950/8000,ZLT2000/3950/8000,JSQ200/3950/8000,CLSQ200-4/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200-6/3950/8000,SQS200/3950/8000,SQS200/3950/8000,SQS200/3950/8000, SQS200/3950/8000,ZLT1750/3950/7000,ZLT2000/3950/8000,URG804,URG805,URG806/3950/8000.
